Shiner 12V/24V MPPT Solar Controller / Regulator

Price range: $170.00 through $350.00

Maximise your solar charging efficiency with the Shiner 12V/24V MPPT Solar Controller. Designed for caravans, 4WDs, camping and off-grid systems, it optimises solar energy collection while helping protect your batteries from overcharging. A reliable solution for efficient 12V and 24V solar power management.

Keep your solar system running efficiently with the Shiner 12V/24V MPPT Solar Controller. Designed for off-grid solar applications, this controller helps regulate power from your solar panels to your battery system, improving charging efficiency and helping protect your batteries.

Featuring Maximum Power Point Tracking (MPPT) technology, the Shiner controller optimises solar energy harvesting to deliver effective battery charging under changing sunlight conditions.

Key Features:

  • MPPT technology for efficient solar charging

  • Suitable for compatible 12V and 24V battery systems

  • Optimises solar panel power output

  • Helps prevent battery overcharging

  • Ideal for caravans, camper trailers, 4WDs and off-grid solar setups

  • Designed for reliable solar power management

Whether you’re travelling off-grid or setting up a standalone solar system, the Shiner MPPT Solar Controller is a practical solution for managing your solar charging needs.

TECHNICAL PARAMETERS

Static power consumption ≤10mA
Battery Type SLD/GEL/FLD/LI/USE/USELI, SLD as default
System voltage 12V/24V
Battery operating voltage range 8V-32V
MPPT tracking efficiency >99%
Charging conversion efficiency 85%-98% (10%-100% of rated power)
Rated load current 20A
Load operating mode Light control, light control + time control, manual mode (default), debugging mode, normally open



Protection function PV overvoltage protection, PV reverse connection protection, PV short circuit protection, night reverse charging protection, input power limit protection, over-temperature protection, load short-circuit protection, overload protection, battery over-voltage/over-discharge protection, battery reverse connection protection, battery end short circuit protection.
Grounding type Grounding of common negative electrode
Operating ambient temperature range -35℃~65℃
Protection grade IP32
Cooling mode Natural heat dissipation
